ASSISTENT AS post mounted jib crane, without electric chain hoist, max. load 1000 kg, reach 3 m.

ASSISTENT AS post mounted jib crane, without electric chain hoist, max. load 1000 kg, reach 3 m.

Original price was: $4,059.00.Current price is: $2,618.78.

99 in stock

SKU: YPL801575162968 Category:

Estimated delivery: 52 days

ASSISTENT AS post mounted jib crane, without electric chain hoist, max. load 1000 kg, reach 3 m

  • Supplied = flat pack
  • Swivel range = 270
  • Design of rotary crane = crane without electric chain hoist
  • Flange width = 120 mm
  • Overall height = 2845 mm
  • Height of lifting gear = 573 mm
  • Reach = 3000 mm
  • Crane jib bottom edge = 2500 mm
  • Colour = daffodil yellow RAL 1007
  • Material = steel
  • Product type = post mounted jib cranes
  • Customs tariff number = 84261100
  • Country of origin = DEU
  • Gross weight = 528.35 kg
  • Weight = 528 kg
  • Sustainability = CO 2footprint calculated
  • Compact design, ideally suited for low rooms
  • High quality craftsmanship
  • Flexible assembly with several related products
  • The versatile workplace crane is ideally suited for low and narrow workshops with little space
  • Regardless of whether it is used in a hall or outdoors, the individual post height and the stabiliser length means it adapts perfectly to your needs
  • With a swivel range of 270, it can quickly and easily move loads or machine components to the closest workplace
  • Constructed according to EN directives and EU machine guidelines for light industrial use
  • Included in delivery:Standard electrical system with lockable mains cut-off switch and power supply to hoist
  • Cable holding bracket up to 3 m jib length, round trailing cable for min. jib length of 4 m
  • Dolly buffers on front and back
  • Securing bolt system VAS2
  • Detailed documentation is included in delivery
  • Securing bolt system VAS2:For direct mounting to B25 concrete floors, min. thickness 170 mm
  • Can be put into service immediately after assembly – no base casting required on even floor
  • Uneven flooring (up to 10 mm) compensated by underlay
  • Includes recessed plugs – no tripping hazard
  • Does not include chassis and electric chain hoist
  • The technical specifications for these cranes makes it necessary to manufacture them to order – no right of return
  • You couldn’t find the right model? Other load capacities, reaches, overall heights, paint coats and mounting systems available on request.
